APPLICATION/DESCRIPTION:
Cutting boards and grooves in raw or coated chipboard, MDF, HDF
Sizing, milling and grooving of chipboard, MDF. HDF boards with or without laminate
MACHINE/MACHINERY:
Pantographs and CNC Machining Centers with table ripping
CNC Routers with flat table
TECHNICAL INFORMATION:
Polycrystalline diamond cutting teeth DP H2,5 mm – high quality integral HW body .
The resistance of the HW body allows the creation of cutters with reduced diameters and cutting lengths
superior to cutters made with a steel body.
Drilling into the positive axial DIA remaining part of the negative cutting edge
With diamond horizontal tooth /PCD/ on top and up/down compression design
-13%Hot
6039-Diamond milling cutter 12x25 Z=1+1 Price range: 34.51€ through 80.53€ excl. VAT
Diamond Conical Trimmer Price range: 145.00€ through 242.00€ excl. VAT
6041-Diamond milling cutter with solid alloy body (HM)
Price range: 46.02€ through 115.04€ excl. VAT
Description
| Sku | D | L | dxs | LT | Nr-of-tips | Nr-of-tips | Price | Buy |
|---|---|---|---|---|---|---|---|---|
| 6041 008 020 | 8 | 20 | 8х40 | 70 | 2+1 | 1 | Original price was: 52.92€.46.02€Current price is: 46.02€. excl. VAT | |
| 6041 008 027 | 8 | 27 | 8х40 | 75 | 3+1 | 1 | Original price was: 70.56€.61.36€Current price is: 61.36€. excl. VAT | |
| 6041 008 035 | 8 | 35 | 8х40 | 80 | 4+1 | 1 | Original price was: 95.25€.82.83€Current price is: 82.83€. excl. VAT | |
| 6041 010 027 | 10 | 27 | 10х40 | 75 | 3+1 | 1 | Original price was: 82.93€.72.09€Current price is: 72.09€. excl. VAT | |
| 6041 010 035 | 10 | 35 | 10х40 | 80 | 4+1 | 1 | Original price was: 100.72€.87.43€Current price is: 87.43€. excl. VAT | |
| 6041 010 044 | 10 | 44 | 10х40 | 90 | 5+1 | 1 | Original price was: 111.15€.105.84€Current price is: 105.84€. excl. VAT | |
| 6041 012 027 | 12 | 27 | 12x40 | 80 | 3+1 | 1 | Original price was: 91.73€.79.76€Current price is: 79.76€. excl. VAT | |
| 6041 012 035 | 12 | 35 | 12x40 | 90 | 4+1 | 1 | Original price was: 109.42€.95.10€Current price is: 95.10€. excl. VAT | |
| 6041 012 044 | 12 | 44 | 12x40 | 90 | 5+1 | 1 | Original price was: 132.42€.115.04€Current price is: 115.04€. excl. VAT |
